adiabatic smart cooling

Adiabatic Smart cooling systems

Welcome to DUBITECS, the leading company for energy and environmental solutions. We are proud to provide the most innovative and efficient adiabatic smart cooling system available in the market. Our system is produced in Italy by Idrobase, one of the world’s largest high-pressure pumps and misting systems manufacturers, ensuring the highest quality and reliability.

Our DUBICOOL adiabatic smart cooling system is designed to enhance your comfort and productivity while reducing your energy consumption and environmental footprint. By leveraging the principles of evaporative cooling, our system can cool the air temperature by up to 15°C with energy consumption that is up to 80% lower than traditional air conditioning systems.

At DUBITECS, we understand that each application is unique, which is why we offer customizable solutions to fit your specific needs. Our adiabatic smart cooling system can be integrated into a wide range of applications, including industrial, commercial, agricultural, and residential. Whether you are looking to cool a factory floor, a warehouse, a greenhouse, or a patio, we have the right solution for you.

Introduction:

Air conditioning and cooling units have a specific calculation of efficiency that specifies the cooling power provided by the unit at a specific temperature of the air entering the system. The higher the inlet air temperature, the higher the power consumption required for the necessary cooling capacity. The average decrease of air temperature by 1°C improves the efficiency of air conditioning and cooling units by 1.8%. With the use of the adiabatic pre-cooling misting system, the temperature of the air entering air conditioning and cooling units drops by an average of 10 – 20°C, resulting in energy savings of up to 30%.

How it works

Evaporative cooling takes advantage of the potential of the outside to absorb moisture, which results in a temperature reduction of the air stream. When evaporative cooling is used for pre-cooling condenser inlet air, the condenser operates at a lower temperature than a baseline air-cooled condenser and needs less power demand and electricity to meet the cooling demand

The relative humidity is the amount

of moisture in the air compared to the

amount of moisture the air could absorb

at the same temperature, is a crucial factor

in determining cooling potential.

The lower the relative humidity,

the more water can be vaporized,

and the more heat can be removed.

Evaporative Cooling can be used effectively

in most geographical locations.

This is because when temperatures reach their peak during the day, humidity is normally at its lowest point.

In air conditioning systems, condensing units reject heat from refrigerants directly into the outside air stream.

In these systems, higher outside air temperatures result in higher energy use by the compressors.

As a result, as the outdoor air temperature rises, the efficiency of the air conditioning system drops and requires more energy to provide the same amount of cooling to the conditioned space.

To compound this issue, more space cooling is necessary on days when the outdoor air temperature is higher, due to the increased heat load on the building.

Applying a water fogging system to air-cooled chillers can improve efficiency under most working conditions, as the water mist could lower the air temperature entering the condenser.

System Components

Our system consists of several components, including a high-pressure misting system, an intelligent control system, a water treatment system, and protective membranes, all designed to maximize the efficiency and longevity of the system. Our high-pressure misting system features stainless-steel pipes, nozzles, and polyamide pipes, ensuring durability and efficiency. Our intelligent control system is connected to temperature and humidity sensors and analyzes the performance of the cooler to operate the pre-cooling circuit as per-programmed operation modes. Our water treatment system includes an electronic filter and UV sterilizer, ensuring the purity of the water and increasing the longevity of the system. Finally, our protective membranes protect the condenser from direct exposure to water droplets and dust.

a) The High-Pressure Misting System

  • High-pressure misting pumps
  • Misting lines made of stainless-steel pipes ø9,6 mm
  • Stainless steel nozzles on each chiller Size: 0.2
  • Polyamide pipes
  • Fittings & Accessories
  • Stylish strong Aluminium brackets

b) The Intelligent Control System

  • Humidity & Temperature probe: RS485 Modbus Water Proof Temperature Humidity Sensor Probe
    • Measuring Precision: Temperature: ±0.5℃ (resolution: 0.1℃) / Humidity: ±5%rh (resolution: 0.1 rh)
    • Output: RS485 (Protocol MODBUS RTU)
  • Control system (PLC) connected with temperature and RH sensors and with the chiller’s control panel
  • Water treatment system

c) Water Treatment System

  • Limescale Electronic filter: Dropson new generation anti-scaling system
  • Kit for water filtration (1 + 5 Micron) complete with pressure stabilizer, support bracket, 5 and 1mcr string-wound cartridges, connection hose, tightening spanner, and spare
  •  cartridges (5+5 pcs)
  • UV Water sterilizer

d) Protective Membranes

  • Aluminum Structure
  • 100% polyester construction
  • Works as an air filter to protect the chiller from dust and wet media
  • Thicknesses: 1 inch
  • Rigid construction
  • Low resistance to airflow; reduces energy cost
  • Fibers are unaffected by water
  • Safe to handle; no fiberglass or sharp edges
  • Bi-directional airflow; installs either side out
  • High dust retention (80-90% dust retention)
  • Flame retardant/self-extinguishing!
  • Flame retardant UL Class II – self-extinguishing FMVSS302 Certified
  • Easy to remove for chiller cleaning

Smart Adiabatic System Key Features:

Our adiabatic smart cooling system includes several key features to ensure optimal efficiency, including:

  • Pre-cooling ambient air of the air entering the condensers decreases compressor power and improves the chiller performance by applying high-pressure water mist.
  • Reducing gas pressure in the chiller gas circuit to minimize compressor load, increase COP, and reduce energy consumption.
  • One dedicated HP pump and misting line for each chiller circuit to increase the efficiency of the system and reduce water consumption.
  • Water treatment system to protect the chiller from calcium (limescale), legionella, and mineral deposits.
  • Supplied with protective membrane panels to protect the condenser from direct exposure to water droplets, sun, and dust, as well as the absorption of non-evaporated water.
  • Modbus rs485 (BMS) communication protocols to enable the system to be connected and monitored by BMS.
  • Possibility of linking the system to cloud energy monitoring platforms to monitor the performance of the pre-cooling system.
  • An intelligent control system (PLC) connected with temperature and RH sensors and with the chiller’s control panel, which analyzes the performance of the cooler (load – gas pressure – temperature, and fan logarithm) to operate the pre-cooling circuit and achieve the best efficiency.
  • The possibility of changing the control parameters manually to calibrate the system, which is designed to operate more efficiently and with the lowest possible water consumption.

By choosing DUBITECS, you are not only investing in a state-of-the-art adiabatic smart cooling system, but you are also contributing to a better future for our planet. Our system’s reduced energy consumption and environmental footprint make it an excellent choice for those seeking sustainable solutions.

Contact us today to learn more about our adiabatic smart cooling system and how we can help you enhance your comfort and productivity while reducing your environmental impact. Our team of experts will be happy to assist you and provide you with a tailored solution that meets your specific needs.
